• Frequency Range (+/-3 dB): 70 Hz – 30,000 Hz

• Sensitivity (2.83V/1m): 89 dB

• Nominal Impedance: 4 ohms

• Maximum SPL: 109 dB

• Recommended Amplifier Power: 30 – 150 Watts

• Crossover Frequencies: 2,800 Hz / 14,000 Hz

• Crossover Principle: 2 + ½-way

Driver Configuration

• High-Frequency Drivers: Hybrid tweeter module

• 1 x 29 mm Soft Textile Dome

• 1 x 17 x 45 mm Ribbon

• Low-Frequency Driver: 1 x 6½" Wood Fiber Cone with SMC (Soft Magnetic Compound) magnet system.

Design & Build

• Enclosure Type: Bass Reflex (dual rear-mounted, downward-firing ports designed to use the wall for bass extension).
